Technical parameter:
Model | JX-QD600 |
Material | 304不锈钢 |
Voltage Frequency | 380V/50HZ |
power | 2.25KW |
yield | 1000kg/h |
weight | ≈200KG |
Shape size | L2410*W1210*H1725mm |
Product Profile:
●This machine is suitable for cutting, cutting, cutting and so on in food processing enterprises, continuous production lines. It is generally used in combination with steam line or other conveying lines. It is often used in cutting and slicing of production lines of fish tofu, crab steak, fish stick and other products. It adopts man-machine interface, and the length of cutting can be adjusted arbitrarily.
●The machine adopts Delta servo motor control, which can accurately control the consistency of product length.
●The structure of the machine is made of 304 high quality stainless steel, the conveyor belt is made of food grade PU, and the cutting knife is made of special stainless steel.
●The machine is reasonable in design, safe in operation, simple and easy to understand, and more convenient in cleaning and maintenance.
●The machine's direct contact with food fittings conforms to international health standards.
Equipment configuration:
1. The rack adopts: 50*50*2 square pipe and 45*75*2 square pipe material SUS304.
2. Desk panel: SUS304 with 2.0mm thickness
3. Motor parameters: NMRV63 reducer + micropendulum NMRV63_100_4P_0.75KWSC Series Helical Tooth-Worm Reduction Motor (with Frequency Converter)
4. Servo motor: Delta's MOTOR_F130 (1315RS) 1.5KW servo motor
5. Servo reducer: ST140-FO-110M8 speed ratio = 1:5
